2pc M/F full port ball valve
Product No.:HV-21MF
Working pressure:1000PSI(PN69)
Working temperature:-10oC-150oC
Suitable medium:water oil gas
Threaded end:BSPT NPT ISO7/1 ISO228
Product No.:HV-21MF
Working pressure:1000PSI(PN69)
Working temperature:-10oC-150oC
Suitable medium:water oil gas
Threaded end:BSPT NPT ISO7/1 ISO228
| SIZE | D | A | L | H | W |
| 1/4" | 9.2 | 12.5 | 62 | 50 | 98 |
| 3/8" | 12.8 | 13 | 64 | 50 | 98 |
| 1/2" | 15 | 15 | 69 | 50 | 100 |
| 3/4" | 20 | 16.5 | 80.5 | 53 | 100 |
| 1" | 25 | 19 | 95 | 68.5 | 128 |
| 11/4" | 32 | 22 | 107 | 72.5 | 128 |
| 11/2" | 38 | 22 | 120 | 81 | 143 |
| 2" | 50 | 26 | 142 | 99 | 143 |
| NO.1 | NAME | MATERIAL | Q'TY |
| 1 | HANDLE COVER | PLASTIC | 1 |
| 2 | BODY | CF8M | 1 |
| 3 | BALL SEAT | PTFE | 2 |
| 4 | BALL | CF8M | 1 |
| 5 | CAP | CF8M | 1 |
| 6 | JOINT GASKET | PTFE | 1 |
| 7 | THRUST WASHER | PTFE | 1 |
| 8 | STEM PACKING | PTFE | 1 |
| 9 | GLAND NUT | 304 | 1 |
| 10 | SPRING WASHER | 304 | 1 |
| 11 | STEM NUT | 304 | 1 |
| 12 | STEM | 316 | 1 |
| 13 | LOCK DEVICE | 304 | 1 |
| 14 | HANDLE | 304 | 1 |
